Zhone 100 - Txcir & Rxcir Modes; Figure 5-11 PVC Statistics Summary Screen (Txcir & Rxcir Mode)

5 Diagnostics
980-001-0210G NetPath 100 User’s Manual - Installation Guide 5-17
June
1999
TxCir & RxCir
Modes
The TxCir Mode screen display is shown in Figure 5-11.
Fi
g
ure 5-11 PVC Statistics Summar
y
Screen (TxCIR & RxCIR Mode)
TxCIR and RxCIR Modes - Display the Tx or Rx traffic level for each PVC based on
the time spent at each range of CIR.
xxx% (of CIR), column headings - Indicate the range of values assigned on the
PVC Performance Configuration Screen to each of the “Bins” (columns). In
the example shown above, the CIR ranges for the eight Bins are:
| 0 | 1 - 25 | 26 - 35 | 36 - 50 | 51 - 71 | 72 - 100 | 101 - 141 | > 141 |
xxx% (of Time) - Indicates the percentage of available seconds during which the
traffic level for this PVC was within this Bin’s CIR range.
UAS - UnAvailable Seconds determined by LMI reporting that the PVC is not
fully active or while Netw LMI Failure exists.
(UAS counts are not maintained for the NetPath’s WAN Management PVC.)
CIR Kbps - Current CIR value being used for percent of usage calculations
(binning), for each PVC listed.
**************************** PVC Statistics Summary ****************************
Name: F243802 Mode[M=P,O,TC,RC,TL,RL,FD,orND]:TxCir
(P=Pkt,O=Oct,TC=TxCir,RC=RxCir,TL=TxLoss,RL=RxLoss,FD=FullDlay,orND=NetwDlay)
First DLCI[P=#]: 16 Current Interval Count: 455 of 900 secs CIR
DLCI | 0 |1-25 | -35 | -50 | -71 | -100| -141| >141%(ofCIR) UAS Kbps
25 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
33 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
234 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
341 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
464 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
531 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
793 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
795 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
942 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
Etc
Sum 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime)
-- 15 Min Interval History: 96 Valid -- Past Summary for DLCI [D=#orSum]: 25 --
| 0 |1-25 | -35 | -50 | -71 | -100| -141| >141%(ofCIR) UAS Kbps
10 Secs: 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
History: 100.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0%(ofTime) 0 0
ResetStats[RS] ViewHistory[VH current_time(optional)]
Help[?] Close[X] NextPage[+] AutoUpdate[AU]
>
