4 Operation
4-18 NetPath 100 User’s Manual - Installation Guide 980-001-0210G
June
1999
Frame Manager
Configuration
The Frame Manager Configuration screen allows you to view and alter parameters for
Frame Manager operations.
The Frame Manager Configuration screen is shown in Figure 4-9.
Fi
ure 4-9 Frame Mana
er Confi
uration Screen
Configure Frame Manager
1. WAN Mgmt DLCI - Displays current DLCI value of the private network PVC or
Tunneled PVC for WAN management of the NetPath 100, as stored in the unit’s
non-volatile memory (NVM). This value may be entered using the unit’s rear
panel DLCI DIP Switches, or entered from this screen. Enter only DLCI number
for private network PVC, or preface DLCI number with “T” for tunneled PVC.
2. P/C Mgmt DLCI - Sets or disables the direction and PVC for Payload/CPE
management access to the NetPath 100. The first letter (P or C) determines which
direction, and the remainder indicates the DLCI value.
NOTE: The P/C Mgmt DLCI value must NOT be the same as WAN Mgmt DLCI.
CAUTION
If either WAN or P/C M
mt DLCI value is chan
ed, the
NetPath 100 will perform a system reset after the Save
[SA] command is issued. The system reset will terminate
any console session in pro
ress and interrupt data
traffic.
3. LMI Protocol - Displays and allows the selection of the LMI protocol used. If set
to “None,” LMI traffic (if any) to or from the Network will be passed through the
NetPath unaffected, and the unit’s LMI alarms and status will be cleared.
4. Network (DTE) - Consists of the settings required for the various protocols. These
include T391, N392, N393 and N391.
************************** Frame Manager Configuration *************************
Name: F@43802
LMI Protocol [P=]
WAN Mgmt DLCI [D=#orT#]: Disabled 1) None 3) "LMI"
P/C Mgmt DLCI [E=P#orC#]: Disabled >>2) ANSI"D" << 4) ITU"A"
X to Disable or 16 thru 991
------------- Network ------------ -------------- User --------------
T391/Status Enq Rate [S1=#]: 10 T392/Status Enq Timeout [S2=#]: 15
5 thru 30 seconds 5 thru 30 seconds
N392/Event Err Thres [T1=#]: 3 N392/Event Error Thres [T2=#]: 3
N393/Event Count [C1=#]: 4 N393/Event Count [C2=#]: 4
1 thru 10 1 thru 10
N391/Full Status Freq [F1=#]: 6 Force Full Status Response [F2=]
1 thru 255 >>1) Disable<<
2) Enable
PVC BECN/FECN Thres [B=#]: Disabled
X to Disable or 1 thru 895 seconds
Link Err Thres [L1=#]: Disabled Link Err Thres [L2=#]: Disabled
X to Disable or 1 thru 895 seconds X to Disable or 1 thru 895 seconds
Help[?] Save[SA] Cancel[X]
>
