CSU / DTE
Configuration
The CSU / DTE Configuration screen allows you to view and alter parameters for the
CSU and DTE interface operations.
The CSU / DTE Configuration screen is shown in Figure 4-8.
Fi
ure 4-8 CSU / DTE Confi
uration Screen
1. T1 ID - Enter an ID for this T1.
2. Data Rate - Displays the data rate which results from the settings for “Number of
DS0’s” and “DS0 Format.”
3. Number of DS0’s, Starting DS0, and DS0 Pattern - Select which DS0s will be
used to form the data payload.
4. DS0 Format - Select data rate for all DS0s in the payload.
5. Build Out - Selects the Line Build-Out value for the T1 line connection.
6. Ones Dens - Selects the Ones Density format to be used.
7. T1 Framing - Selects T1 Framing format to be used.
NOTE: ANSI or AT&T are ESF format, SF includes D4.
8. DTE TxD Clk - Configure the DTE to clock in the Tx data based on either the
DCE (NetPath) supplied clock, or the DTE (cable loop or router) supplied clock.
9. Link Err Thres - Disables or sets the threshold of Rx Errored Seconds plus
Unavailable Seconds which when reached or exceeded will cause an alarm to be
declared.
**************************** CSU / DTE Configuration ***************************
Name: F@43802
T1 ID [I=]: NONAME
Data Rate: 1344 kbs Build Out [B=] T1 Framing [T=]
>>1) T1-0<< >>1) ANSI<<
Number of DS0's [N=]: 24 2) T1-7 2) AT&T
Starting DS0 [S=]: 1 3) T1-15 3) SF
1 thru 24 4) T1-22
DS0 Pattern [P=] DS0 Format [F=] Ones Dens [D=] DTE TxD Clk [C=]
>>1) Contiguous<< >>1) Nx56 kbs<< >>1) B8ZS<< >>1) DCE<<
2) Alternate 2) Nx64 kbs 2) AMI 2) DTE
Link Err Thres [L=#]: Disabled
X to Disable or 1 thru 895 seconds
Help[?] Save[SA] Cancel[X]
>
