3 Installation
980-001-0210G NetPath 100 User’s Manual - Installation Guide 3-17
June
1999
Cisco HD-60
Adapter Cable
Specifications
To connect a Cisco* router to a NetPath 100 Data Port configured for ITU-V.35, use
CRC cable assembly # 135-006-0400, or per pinout shown in Table 3-13.
* Cisco is a registered trademark of Cisco Systems, Inc.
Table 3-13 Cisco HD-60M to NetPath 100 HD-44M
Cisco
HD-60M
Pin
DB-44M
Pin
Si
g
nal
Cisco
HD-60M
Pin
DB-44M
Pin
Si
g
nal
Shield Shield Shield 27 33 RD-B
17 32 TD-B
28 18 RD-A
18 17 TD-A 33 8 DCD(s)
19 44 TCE-B
34 6 DSR(s)
20 29 TCE-A
35 5 CTS(s)
23 40 TC-B 42 4 RTS(s)
24 25 TC-A
43 9 DTR(s)
25 42 RC-B
45 7 Sig. Gnd.
26 27 RC-A 46 1 Shield
NOTES:
Shielded cable is required.
Twisted Pair cable conductors for HD-60 pins: 17 & 18, 19 & 20, 21 & 22,
23 & 24, 25 & 26, 27 & 28, 33 & 34, 35 & 42, 43, & 44, 45 & 46.
HD-60 pins tied: 48 to 49, 50 to 51 to 52, 53 to 54 to 55 to 56.
HD-44 pins tied: 17 to 37 via resistor, 32 to 37 via resistor,
22 to 28 to 30, then all to 29 via resistor,
22 to 28 to 30, then all to 44 via resistor
(Resistor = 300 Ohm, 1/4 W, 5%).
(s) = single ended.
