Appendix
980-001-0210G NetPath 100 User’s Manual - Installation Guide A-3
June
1999
Drop Zero to Netw All Zeros pattern BERT is being sent toward the Network Circuit (for DS0s assigned to
Drop Port.)
2047 to Drop 2047 pattern BERT is being sent toward the Drop Circuit.
Test Pkts to Netw Link Test Packets (40 -1590 octets) are being sent toward the Network Circuit (only on
the DS0s assigned to the User Port.)
DSX Lp to Netw Loopback is in place at the DSX Port (for DS0s assigned to DSX Port @ Nx64K)
toward the Network Circuit.
V54 User Lp to Netw Loopback is in place at the User Port toward the Network Circuit, in response to a V.54
LoopUp code from the Network (only if DS0s are assigned to the User Port.)
V54 Drop Lp to Netw Loopback is in place at the Drop Port toward the Network Circuit, in response to a V.54
LoopUp code from the Network (only if DS0s are assigned to the Drop Port.)
LL Lp to User Loopback is in place at the User Port toward the User Circuit, in response to an LL
(Local Loopback) signal at the User Port interface (only if DS0s are assigned to the
User Port.)
LL Lp to Drop Loopback is in place at the Drop Port toward the Drop Circuit, in response to an LL
(Local Loopback) signal at the Drop Port interface (only if DS0s are assigned to the
Drop Port.)
Table A-1 Active Test
Display Description
