Function Name Description
Serial Port
No Using: No communication with the device
through the serial port.
Master Unit: When OSDP
function of "Master unit", it can be connected
to a card reader.
OSDP Output: Communicate with the device
through the OSDP serial port.
Baudrate
There are 5 baudrate options at which the data
communicates with the PC. They are: 115200
(default), 57600, 38400, 19200 and 9600.
The higher the baudrate, the faster is the
communication speed, but also less reliable.
Hence, a higher baudrate can be used when the
communication distance is short; when the
communication distance is long, choosing a
lower baudrate is more reliable.
