ZKTeco SC800 User Manual

SC800 User Manual
Page | 90 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
17 Connect to ZKBio Access IVS Software
Set the Communication Address 17.1
 Device side:
1. Tap COMM. > Ethernet in the main menu to set the IP address and
gateway of the device.
(Note: The IP address should be able to communicate with the ZKBio
Access IVS server, preferably in the same network segment with the server
address).
2. In the main menu, click COMM. > Cloud Server Setting to set the server
address and server port.
Server address: Set the IP address as of ZKBio Access IVS server.
Server port: Set the server port as of ZKBio Access IVS (The default is 8088).
 Software side:
Login to ZKBio Access IVS software, click System > Communication >
Communication Monitor to set the ADMS service port, as shown in the figure
below:

ZKTeco SC800 Specifications

General

Brand	ZKTeco
Model	SC800
Category	IP Access Controllers
Language	English
