Wiring Description 4.6
4.6.1 Power Connection
Recommended AC Adapter
1. 12V ± 10%, at least 3A.
2. To share the power with other devices, use an AC Adapter with higher
current ratings.
4.6.2 Ethernet Connection
Connect the device and computer via an Ethernet cable, as shown in the
example below:
Note: In LAN, the IP addresses of the server (PC) and the device must be in the
same network segment when connecting to the software.
