Zoom H5 User Manual

Other functions
Using SD cards from older H series recorders
111
H5 Handy Recorder
Using SD cards from older H series recorders
1. Insert the SD card, and then turn the on.
2. Use to select
“YES", and press
.
An SD card that has been used in an older ZOOM H series recorder can be read by an and its files moved for its use.
NOTE
•
This function cannot be used to move projects created
by an
.
•
When files created in 4CH MODE are moved, a project
named "ZOOMXXXX" will be created.
•
Moved files will have the name of the H series model
that they came from added to the beginnings of their
names.
•
If a file with the same name already exists on the des-
tination, movement will not be possible until the file
name is changed.

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
