Zoom H5 User Manual

Tools
Setting the recording format
89
H5 Handy Recorder
Setting the recording format
1. Press .
2. Use to select “REC", and press .
MULTI FILE mode STEREO FILE mode
3. Use to select
“REC FORMAT", and
press
.
4. Use to select
recording format, and
press
.
Select the format according to the desired audio quality and file size.
WAV 96kHz/24bit
WAV 96kHz/16bit
WAV 48kHz/24bit
WAV 44.1kHz/24bit
WAV 48kHz/16bit
WAV 44.1kHz/16bit
MP3 320kbps
MP3 256kbps
MP3 224kbps
MP3 192kbps
MP3 160kbps
MP3 128kbps
MP3 112kbps
MP3 96kbps
MP3 80kbps
MP3 64kbps
MP3 56kbps
MP3 48kbps
WAV 48kHz/24bit
WAV 44.1kHz/24bit
WAV 48kHz/16bit
WAV 44.1kHz/16bit
Audio quality File sizeSTEREO FILE modeMULTI FILE mode
High
Low
Large
Small
Recording formats that
can be selected when
backup recording is ON
NOTE
•
Use the WAV format for recording high-quality audio.
•
The MP3 format reduces file size through compression,
but this also reduces the audio quality. Use this format
if you need to conserve space or store many recordings
on an SD card, for example.
•
When using the backup recording function in STEREO
FILE mode, some formats cannot be selected.

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
