Zoom H5 User Manual

Appendices
Specifications
114
Recording media 16MB–2GB SD cards, 4GB–32GB SDHC cards
Inputs
L/R inputs
XY mic (XYH-5)
Mic type
Directional
Sensitivity
–45 dB, 1 kHz at 1 Pa
Input gain –∞ to 52 dB
Maximum sound pressure input
140 dBSPL
MIC/LINE IN stereo mini jack Input gain: –∞ to 52 dB
Input impedance: 2 kΩ or more
Plug-in power supported
Backup input Set L/R input gain –12 dB
1/2 INPUTS
Connectors XLR/TRS combo jacks (XLR: 2 hot, TRS: TIP hot)
Input gain (PAD OFF) –∞ to 55 dB
Input gain (PAD ON) –∞ to 35 dB
Input impedance 1.8 kΩ or more
Maximum allowable input level +22 dBu (PAD ON)
Phantom power
+12/+24/+48 V (can be turned ON/OFF independently for INPUTS 1/2)
Equivalent input noise (EIN) –120 dBu or less
Out-
puts
Output jacks
LINE OUT stereo mini jack (rated output level –10 dBm when output load impedance is 10 kΩ or more)
PHONE OUT stereo mini jack (20 mW + 20 mW into 32Ω load)
Built-in speaker
400mW/8Ω mono speaker
Recording formats
STEREO FILE mode
Supported WAV formats: 44.1/48/96kHz, 16/24-bit, stereo, BWF format supported
Supported MP3 formats: 48–320 kbps, 44.1kHz sampling frequency
Maximum simultaneous recording tracks
4 tracks (L/R + backup recording)
MULTI FILE mode
Supported formats: 44.1/48kHz, 16/24-bit, mono/stereo, BWF format supported
Maximum simultaneous recording tracks 6tracks (L/R + 1/2 +backup recording)
Display
LCD (128 x 64) with backlight
Specifications

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
