USB functions
Audio interface settings
74
Audio interface settings
When using the as an audio interface, you can make the following settings. Refer to each section for details.
Input settings LO CUT ( P. 93)
COMP/LIMITER ( P. 94)
In1/2 PHANTOM ( P. 96)
PLUGIN POWER ( P. 97)
In1/2 PAD(-20dB) ( P. 98)
1/2 MS STEREO MATRIX ( P. 86)
L/R MS-RAW MONITOR ( P. 85)
DIRECT MONITOR ( P. 74)
MONITOR MIXER
( P. 75)
(MULTI TRACK only)
LOOP BACK ( P. 77) (STEREO only)
In1/2 MONO MIX ( P. 88)
(STEREO only)
LINE OUT LEVEL ( P. 84)
Tool TUNER ( P. 78)
Making direct monitoring settings
Sound that is input to the can be output directly
before it passes through the connected computer or iPad.
This enables monitoring without latency.
1. Press .
2. Use to select “IN/
OUT", and press
.
3. Use to select “DIRECT MONITOR",
and press
.
STEREO
MULTI TRACK
For STEREO skip to set 5.
