Zoom H5 User Manual

Preparations
Supplying power
12
Supplying power
Using batteries
1. Turn the power off and then remove the battery
cover.
Push down
and open
2. Install the batteries.
3. Replace the battery cover.
NOTE
•
Use alkaline batteries or
rechargeable NiMH batteries.
•
If the battery indicator
becomes empty, turn the
power off immediately and
install new batteries.
•
Set the type of battery being
used. (→ P. 17)
Preparations
Using an AC adapter
1. Connect a USB cable to the USB port.
2. Plug the adapter into an outlet.

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
