Zoom H5 User Manual

Tools
Using the tuner
78
1. Press .
2. Use to select
“TOOL", and
press
.
3. Use to select
“TUNER", and
press
.
Using the tuner
You can use the input signal to tune an instrument.
4. Use to select the
type of tuning, and
press
.
5. Use to change the
standard pitch.
HINT
The standard pitch can be set from 435 Hz to 445Hz.
Tools

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
