Zoom H5 User Manual

USB functions
Data exchange with computers (card reader)
70
1. Press .
2. Use to select
“USB", and press
.
3. Use to select “SD
CARD READER", and
press
.
4. Connect the to the computer using a USB
cable.
NOTE
•
If you want to power the
using the computer’s
USB bus, connect the cable while the recorder is off and
then turn it on.
•
The following operating systems are supported.
• Windows Vista or later
• Mac OS X 10.6 or later
Data exchange with computers (card reader)
By connecting with a computer, you can check and copy data on the SD card.
USB functions

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
