Zoom H5 User Manual

Recording
Adjusting the side mic level
31
H5 Handy Recorder
1. Use to adjust the side mic level
Adjusting the side mic level
Wide
RAW mode
Icon changes
with the value
Narrow
When using an input capsule that allows the side mic level (stereo width) to be adjusted, such as an MS capsule, you can
adjust the side mic level before recording.
NOTE
•
Set to Off, −24 to +6 dB, or MS-RAW mode.
•
When recording in MS-RAW mode, during playback
move
up and down to adjust the side mic level.
•
However, this format is different from an ordinary stereo file,
so you will need to use ZOOM MS Decoder or other software
that can convert it to normal stereo in order to use it with other
equipment.
•
MS-RAW mode can be selected only when the WAV format is
used for recording.
MS capsule only

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
