Zoom H5 User Manual

USB functions
Using as an audio interface
72
Using as an audio interface
You can send signals input through the directly to a computer or iPad as well as output signals from that device
through the
.
1. Follow steps 1–2 in "Data exchange with computers
(card reader)" (
→ P. 70).
2. Use to select
“AUDIO INTERFACE",
and press
.
3. Use to select
“STEREO" or "MULTI
TRACK", and
press
.
NOTE
•
Set to “STEREO” to use it as a 2-in/2-out interface or
“MULTI TRACK” to use it as a 4-in/2-out interface.
•
When using an iPad, select "STEREO". It cannot be used
with MULTI TRACK mode.
•
When using Windows, a driver is necessary to use
MULTI TRACK mode. You can download this driver from
the ZOOM website (www.zoom.co.jp).
4. Use to select the connected device,
and press
.
STEREO MULTI TRACK
HINT
If using a computer that does not provide enough power
through its USB bus or using phantom power, select "PC/
Mac (Battery)".

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
