Zoom H5 User Manual

Playback
Basic playback
38
Basic playback
1
2
1
1. Press .
MULTI FILE mode STEREO FILE mode
■ Controls during playback
Select playback project/file
or move to a mark: Use
and
Search forward/backward: Press and hold /
Pause/resume playback: Press
Change side mic level:
(MS-RAW mode only) Move up/down
HINT
•
The longer you press and hold
or , the faster
searching backward/forward becomes.
•
In MULTI FILE mode, during playback you can press track
buttons to unmute (lit green) and mute (unlit) them.
•
If there is a problem with the selected project /file,
"Invalid Project!" or "Invalid File!" will appear on the
display.
•
If there is not even one project /file that can be played,
"No Project!" or "No File!" will appear on the display.
Playback

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
