Lowering the line output level
84
Lowering the line output level
1. Press .
2. Use to select “IN/OUT", and press .
MULTI FILE mode STEREO FILE mode
3. Use to select “LINE OUT LEVEL",
and press
.
MULTI FILE mode STEREO FILE mode
You can lower the output level of the LINE OUT jack. Use this when connecting the LINE OUT jack signal to the external mic
input jack on an SLR camera or other jack with a high input gain.
4. Use to set the LINE
OUT jack output level,
and press
.
NOTE
This setting does not affect the level output from the
PHONE jack.
HINT
LINE OUT LEVEL can be set between −30 and 0 dB.

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
