Zoom H5 User Manual

Tools
Adjusting the input signal monitoring mix
83
H5 Handy Recorder
5. Change parameter
values.
■ Mixing controls
Move cursor/change value: Move
up/down
Select parameter to change: Press
Parameter Setting range Explanation
PAN L100 – CENTER – R100
Adjusts left–right
balance
LEVEL Mute, −48.0 – +12dB Adjusts volume
NOTE
These volume and panning settings only affect the moni-
toring signal. They do not affect recorded data.
6. Press to listen to the
project without mixer
adjustments.
Pressing this button turns
the mixer on and off.
NOTE
These mix settings are saved with each recorded project
separately. Mix settings can also be changed during play-
back. (→ P. 48)

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
