Zoom H5 User Manual

USB functions
Audio interface settings
75
H5 Handy Recorder
4. Use to select
“ON/OFF", and
press
.
5. Use to select “ON", and press .
STEREO MULTI TRACK
MULTI TRACK
Monitor signal mixing (MULTI TRACK only)
When using direct monitoring you can adjust the balance
of the input signals. This mix does not affect the input sig-
nals sent to the computer or iPad.
1. Press .
2. Use to select
“IN/OUT", and
press
.
3. Use to select
“DIRECT MONITOR", and
press
.
NEXT

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
