Zoom H5 User Manual

Tools
Mixing input signals to mono
88
4. Use to select “ON",
and press
.
NOTE
•
When MONO MIX is ON, the names of recording files
will have "_MN" added to the end of the file name, like
"ZOOM0001_MN.WAV".
•
This function cannot be used at the same time as the MS
STEREO MATRIX function. When MONO MIX is turned
ON, MS STEREO MATRIX will be disabled.
1. Press .
2. Use to select
“IN/OUT", and
press
.
3. Use to select
“In1/2 MONO MIX", and
press
.
The signals input through Inputs 1/2 can be mixed to a single signal that is sent to both channels.
Mixing input signals to mono
STEREO FILE mode only Input 1/2 only

Zoom H5 Specifications

General

G-shock sensor	No
Number of cameras	1
Sample rate	96 kHz
Audio quality	24 bit
Audio recording	Yes
Microphone sensitivity	45 dB
Compatible memory cards	SD, SDHC
Power source type	Battery
Product color	Black
Microphone maximum input	140 dB SPL
Microphone input impedance	2000 Ω
Interface	1/8\
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	135.2 mm
Width	66.8 mm
Height	42.1 mm
Weight	176 g
