3D Systems CUBE User Manual

63D Systems, Inc.
5
SPECIFICATIONS AND REQUIREMENTS
WEIGHT
Maximum Cube Weight (with cartridges): 17 lbs. (7.7 kg)
Maximum Box Weight: 23 lbs. (10.43 kg)
SOFTWARE
Complimentary Cubify software for Windows and Mac OS X as well as iOS and Android mobile applications. These applications
generate .cube3 le for printing on your printer.
OPENGL VERSION
• OpenGLES 2.0+ on mobile platforms
• Open GL 3.0+ on Windows and Mac (using 3.2 library of GLU)
WINDOWS REQUIREMENTS
• Cubify software runs on 32- and 64-bit operating systems
• Windows 7, 8 and 8.1
• Minimum screen resolution: 1024 x 768
• Windows is required for Ad Hoc Wi-Fi print job submission.
MAC OS X REQUIREMENTS
• OS X 10.8 and 10.9
• Minimum screen resolution: 1400 x 900
ANDROID
• 4.0 ICS (tablets supported)
IOS
• 6.0+ (iPhone4 and newer)
• Minimum screen resolution: iPhone4
WIRELESS OPTIONS
• 802.11b/g with WPS Infrastructure
• Ad Hoc mode
USB MASS STORAGE DEVICE
• USB mass storage device (supplied with the printer) to transfer print les to the printer using the USB inlet port.
ELECTRICAL REQUIREMENTS
Outlet Requirements 100 - 240 Volts, at 50/60 Hz
Electrical Rating: 24V DC, 5 amp.
MATERIAL STORAGE
All polymers degrade with time. The following conditions ensure the material remains high quality:
• Do not unpack cartridges from the foil until the material is needed.
• Store at room temperature: 16-29° C (60 - 85° F)
• Non-condensing relative humidity: 5% - 25%

3D Systems CUBE Specifications

General

Print technology	Plastic Jet Printing (PJP)
Printing material	ABS, Polylactic acid (PLA)
Number of printing colors	16
Maximum build size (WxDxH)	- mm
Plug and Play	Yes
USB version	2.0
Ethernet LAN	No
Card reader integrated	-
Product color	Silver
