943D Systems, Inc.
PRINT PAD MAINTENANCE
Auto Level and Auto Gap can be affected by residual glue or print material adhered to the print pad. The procedures can also be
affected by a print pad that is too shiny.
1. If Auto Gap is unsuccessful after two consecutive attempts, select PLATE
MAINTENANCE.
2. Using the ne-grit sandpaper included with the printer, buff the print pad.
NOTE: Refer to the section titled Clean The Print Pad for specic
instructions.
NOTE: Ensure the print pad is clean and dry before installing it in
the printer.
3. Select the checkmark to continue.
4. Perform the Auto Level and Auto Gap procedures.
Clean The Print Pad
1. Remove the print pad from the printer.
2. Wash all glue and print material from the print pad with warm tap water. If necessary, scrub the print pad with a soft brush.
3. Dry the print pad thoroughly.
4. If residual material is still adhered to the print pad, gently use the scraper to remove it.
5. If portions of the print pad appear shiny, buff the surface (with very light pressure on the included sandpaper) left-to-right in .5”
(12.7 mm) swirling motions until the entire print pad has been treated.
NOTE: It is most important to lightly sand all shiny areas of the print pad so the print pad surface appears matte
in texture.
6. Clean and dry the print pad thoroughly.
7. Reinstall the print pad.
8. Perform the Auto Level and Auto Gap procedures.
