3D Systems CUBE User Manual

803D Systems, Inc.
REPLACING A MATERIAL CARTRIDGE
Caution: Material cartridges should only be replaced by performing the following procedure. Replacing the
cartridge without using the printer menu can damage the printer and print jets and void the manufacturer’s
warranty.
1. Select SETUP.
2. Select CHANGE CARTRIDGE.
3. Select the material cartridge to change.
NOTE: This procedure illustrates changing the right cartridge. The
same concept applies to the left side.
NOTE: The print jet will begin to heat.

3D Systems CUBE Specifications

General

Print technology	Plastic Jet Printing (PJP)
Printing material	ABS, Polylactic acid (PLA)
Number of printing colors	16
Maximum build size (WxDxH)	- mm
Plug and Play	Yes
USB version	2.0
Ethernet LAN	No
Card reader integrated	-
Product color	Silver
