1143D Systems, Inc.
4. Carefully lift the print platform (A) and tape the spacer (B) to the printer in the
location shown.
5. Remove the print pad from the printer.
6. Place the lower insert on top of the print pad and fold the sides outward.
7. Move the print jet mount to the center of the printer and place the top insert over
the mount.
NOTE: The top insert is designed to keep the sides of the lower
insert pressed outward.
8. Place the printer in the protective bag and then place it in the lower foam support
in the box.
A
B
