Chapter 8. Configuring Units
134 3ware Serial ATA RAID Controller User Guide
When you select a drive, an asterisk appears next to it in the left most
column (see Figure 56).
Tip: If you want to use all available drives, press Alt-A to select them all.
Figure 56. Asterisks Next to Selected Drives
2 After all drives for the unit are selected, Tab to the Create Unit button and
press
Enter.
Tip: You can also press Alt-C to choose Create Unit.
3On the
3ware Disk Array screen, make sure that the proper drives are
listed (see Figure 57 for an example for RAID 5).
Figure 57. Create Disk Array Display
4 (Optional) Press Enter and type a name for the unit; then press Enter
again to set the name.
