Sets the level above which the Vumeter is painted in red.
6. Yellow oneZ
Sets the level above which the Vumeter is painted in yellow.
7. Speed
Sets the update speed of the Vumeters, 1 is the slowest, 5 the fastest.
8. Peek Hold
Sets the duration of peak hold in seconds.
IV. System Clock
1. Date
The system date is used to create the Day folder name (YYYY-MM-DD) which contains the files for
that workday.
NB: The workday folder can contain hours past midnight, if the recording session is not
interrupted.
The workday is also used to fill the default MMDD name of the tape reference field.
2. Time
Enter the time from your watch, especially if you just started working in a new time zone.
It should not be confused with the timecode which is used for syncing picture and audio.
V. Display Levels/Attenuation
1. Inputs Levels
In Record, Ppr, and Test positions, inputs levels can be displayed, as soon as a change occurs,
replacing temporarily the metadata and timecode informations.
If enabled, precision can be set: +/-0,1 dB; +/-0,5 dB; +/-1dB.
2. Tracks attenuation
In Record, Ppr, and Test positions, tracks attenuation can be displayed as soon as it changes.
If “Dedicated Panel” is selected, the metadata and timecode information are temporarily
replaced when the Track attenuation is changed. The Track Audio Level is in that case displayed
above the Vumeters.
If “Top of Vumeter” is selected, Track's attenuation will be displayed above Vumeters and Track
audio level is not displayed.
VI. Light
1. Backlight
Adjusts the screen's backlight brightness.
Keep in mind high brightness are power hungry.
2. LED
Adjusts the brightness of the backlit buttons.
VII.Low Power in stop
Cantar X3
60
