118 Application macros
The AC500 Modbus application macro default values for the drive parameters
correspond to the ABB standard macro (parameter 9902, value 1 (ABB STANDARD),
see section ABB standard macro on page 110), with the following differences:
Note: The default slave address of the drive is 2 (parameter 5303 EFB STATION ID),
but if several drives are used, the address must be unique for each drive.
For more information regarding the Starter kit configuration, please refer to
AC500-eCo and ACS355 quick installation guide (2CDC125145M0201 [English]),
and ACS355 and AC500-eCo application guide (2CDC125152M0201 [English]).
No. Name Default value
1001 EXT1 COMMANDS 10 (COMM)
1102 EXT1/EXT2 SEL 8 (COMM)
1103 REF1 SELECT 8 (COMM)
1604 FAULT RESET SEL 8 (COMM)
2201 ACC/DEC 1/2 SEL 0 (NOT SEL)
3018 COMM FAULT FUNC 1 (FAULT)
5302 EFB STATION ID 2
5303 EFB BAUD RATE 192 (19.2 kb/s)
5304 EFB PARITY 1 (8 NONE 1)
5305 EFB CTRL PROFILE 2 (ABB DRV FULL)
5310 EFB PAR 10 101
5311 EFB PAR 11 303
5312 EFB PAR 12 305
9802 COMM PROT SEL 1 (STD MODBUS)
