80 Control panels
How to change the direction of the motor rotation
You can change the direction of the motor rotation in any mode.
Output mode
In the Output mode, you can:
monitor actual values of up to three group 01 OPERATING DATA signals, one
signal at a time
start, stop, change the direction and switch between local and remote control.
You get to the Output mode by pressing until the display shows text OUTPUT at
the bottom.
The display shows the value of one group 01
OPERATING DATA signal. The unit is shown on the
right. Page 83 tells how to select up to three signals to
be monitored in the Output mode. The table below
shows how to view them one at a time.
How to browse the monitored signals
Step Action Display
1. If the drive is in remote control (REM shown on the
left), switch to local control by pressing . The
display briefly shows message “LoC” before
returning to the previous display.
2. To change the direction from forward (FWD shown at
the bottom) to reverse (REV shown at the bottom), or
vice versa, press .
Note: Parameter 1003 DIRECTION must be set to 3
(REQUEST).
Step Action Display
1. If more than one signals have been selected to be
monitored (see page 83), you can browse them in
the Output mode.
To browse the signals forward, press key
repeatedly. To browse them backward, press key
repeatedly.
LOC
REM
LOC
Hz
OUTPUT FWD
491
.
LOC
Hz
OUTPUT REV
491
.
REM Hz
OUTPUT FWD
491
.
REM Hz
OUTPUT FWD
491
.
A
REM
OUTPUT FWD
05
.
REM %
OUTPUT FWD
107
.
