78 Control panels
 Operation
You operate the control panel with the help of menus and keys. You select an option,
eg, operation mode or parameter, by scrolling the and arrow keys until the
option is visible in the display and then pressing the key.
With the
key, you return to the previous operation level without saving the made
changes.
The basic control panel has five panel modes: Output mode, Reference mode,
Parameter mode, Copy mode and Fault mode. The operation in the first four modes
is described in this chapter. When a fault or alarm occurs, the panel goes
automatically to the Fault mode showing the fault or alarm code. You can reset the
fault or alarm in the Output or Fault mode (see chapter Fault tracing on page 349).
After the power is switched on, the panel is in the
Output mode, where you can start, stop, change the
direction, switch between local and remote control and
monitor up to three actual values (one at a time). To do
other tasks, go first to the Main menu and select the
appropriate mode.
How to do common tasks
The table below lists common tasks, the mode in which you can perform them and the page
number where the steps to do the task are described in detail.
Task Mode Page
How to find out the panel firmware version At power up 79
How to switch between local and remote control Any 79
How to start and stop the drive Any 79
How to change the direction of the motor rotation Any 80
How to browse the monitored signals Output 80
How to set the speed, frequency or torque reference Reference 81
How to change the value of a parameter Parameter 82
How to select the monitored signals Parameter 83
How to reset faults and alarms Output, Fault 349
How to copy parameters from the drive to the control panel Copy 85
How to restore parameters from the control panel to the drive Copy 85
REM Hz
OUTPUT FWD
491
.
REM
MENU FWD
PAr
