76 Control panels
Applicability
The manual is applicable to panels with the panel revisions and the panel firmware
versions given in the table below.
To find out the panel revision, see the label on the back of the panel. An example
label and explanation of the label contents are shown below.
To find out the panel firmware version of your assistant control panel, see page 90.
For the basic control panel, see page 79.
See parameter 9901 LANGUAGE to find out the languages supported by the different
assistant control panels.
Basic control panel
 Features
The basic control panel features:
• numeric control panel with an LCD display
• copy function – parameters can be copied to the control panel memory for later
transfer to other drives or for backup of a particular system.
Panel type Type code Panel revision Panel firmware
version
Basic control panel ACS-CP-C M or later 1.13 or later
Assistant control panel ACS-CP-A F or later 2.04 or later
Assistant control panel (Asia) ACS-CP-D Q or later 2.04 or later
ABB Oy, ACS-CP-A
S/N M0
935E0001 RoHS
1 Panel type code
2 Serial number of format MYYWWRXXXX, where
M: Manufacturer
YY: 09, 10, 11, …, for 2009, 2010, 2011, …
WW: 01, 02, 03, … for week 1, week 2, week 3, …
R: A, B, C, … for panel revision
XXXX: Integer starting every week from 0001
3 RoHS mark (the label of your drive shows the valid markings)
32
1

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
