290 Actual signals and parameters
5205 PARITY
ERRORS
Number of characters with a parity error received from the
Modbus link. If the number is high, check that the parity
settings of the devices connected on the bus are the same.
Note: High electromagnetic noise levels generate errors.
0
0…65535 Number of characters 1 = 1
5206 FRAME
ERRORS
Number of characters with a framing error received by the
Modbus link. If the number is high, check that the
communication speed settings of the devices connected on
the bus are the same.
Note: High electromagnetic noise levels generate errors.
0
0…65535 Number of characters 1 = 1
5207 BUFFER
OVERRUNS
Number of characters which overflow the buffer, ie, number
of characters which exceed the maximum message length,
128 bytes.
0
0…65535 Number of characters 1 = 1
5208 CRC ERRORS Number of messages with an CRC (cyclic redundancy
check) error received by the drive. If the number is high,
check CRC calculation for possible errors.
Note: High electromagnetic noise levels generate errors.
0
0…65535 Number of messages 1 = 1
53 EFB PROTOCOL Embedded fieldbus link settings. See chapter Fieldbus
control with embedded fieldbus on page 313.
5302 EFB STATION
ID
Defines the address of the device. Two units with the same
address are not allowed on-line.
1
0…247 Address 1 = 1
5303 EFB BAUD
RATE
Defines the transfer rate of the link. 9.6 kb/s
1.2 kb/s 1.2 kbit/s 1 =
0.1 kbit/s
2.4 kb/s 2.4 kbit/s
4.8 kb/s 4.8 kbit/s
9.6 kb/s 9.6 kbit/s
19.2 kb/s 19.2 kbit/s
38.4 kb/s 38.4 kbit/s
57.6 kb/s 57.6 kbit/s
115.2 kb/s 115.2 kbit/s
5304 EFB PARITY Defines the use of parity and stop bit(s) and the data length.
The same setting must be used in all on-line stations.
8 NONE 1
8 NONE 1 No parity bit, one stop bit, 8 data bits 0
8 NONE 2 No parity bit, two stop bits, 8 data bits 1
All parameters
No. Name/Value Description Def/FbEq
