62 Start-up, control with I/O and ID run
Starting up the drive
WARNING! The start-up may only be carried out by a qualified
electrician.
The safety instructions given in chapter Safety on page 17 must be followed during
the start-up procedure.
The drive will start up automatically at power-up if the external run command is on
and the drive is in the remote control mode.
Check that the starting of the motor does not cause any danger. De-couple the
driven machine if:
there is a risk of damage in case of incorrect direction of rotation, or
an ID run needs to be performed during the drive start-up. ID run is essential only
in applications that require the ultimate in motor control accuracy.
Check the installation. See the checklist in chapter Installation checklist on page
59.
How you start up the drive depends on the control panel you have, if any.
If you have no control panel, follow the instructions given in section Starting up
the drive without a control panel on page 62.
If you have a basic control panel (ACS-CP-C), follow the instructions given in
section Performing a manual start-up on page 63.
If you have an assistant control panel (ACS-CP-A, ACS-CP-D), you can either
run the Start-up assistant (see section Performing a guided start-up on page 68)
or perform a manual start-up (see section Performing a manual start-up on page
63).
The Start-up assistant, which is included in the assistant control panel only, guides
you through all essential settings to be done. In the manual start-up, the drive
gives no guidance; you go through the very basic settings by following the
instructions given in section Performing a manual start-up on page 63.
Starting up the drive without a control panel
POWER-UP
Apply input power and wait for a moment.
Check that the red LED is not lit and the green LED is lit but not blinking.
The drive is now ready for use.
