Technical data 385
Electric power network specification
Voltage (U
1
) 200/208/220/230/240 V AC 1-phase for 200 V AC drives
200/208/220/230/240 V AC 3-phase for 200 V AC drives
380/400/415/440/460/480 V AC 3-phase for 400 V AC drives
±10% variation from converter nominal voltage is allowed as default.
Short-circuit capacity Maximum allowed prospective short-circuit current at the input power
connection as defined in IEC 61439-1:2009 and UL 508C is 100 kA.
The drive is suitable for use in a circuit capable of delivering not
more than 100 kA rms symmetrical amperes at the drive maximum
rated voltage.
Frequency 50/60 Hz ± 5%, maximum rate of change 17%/s
Imbalance Max. ±3% of nominal phase-to-phase input voltage
Motor connection data
Motor type Asynchronous induction motor or permanent
magnet synchronous motor
Voltage (U
2
) 0 to U
1
, 3-phase symmetrical, U
max
at the field weakening point
Short-circuit protection
(IEC 61800-5-1,
UL 508C)
The motor output is short-circuit proof by IEC 61800-5-1 and
UL 508C.
Frequency 0…599 Hz
Frequency resolution 0.01 Hz
Current See section Ratings on page 374.
Power limit 1.5 · P
N
Field weakening point 10…599 Hz
Switching frequency 4, 8, 12 or 16 kHz (in scalar control)
Speed control See section Speed control performance figures on page 145.
Torque control See section Torque control performance figures on page 146.
