Program features 167
A parameter which is triggered by a timed function can be connected to only one
timed function at a time.
Example
Air conditioning is active on weekdays from 8:00 to 15:30 (8 a.m to 3:30 p.m) and on
Sundays from 12:00 to 15:00 (12 to 3 p.m). By pressing the extension time switch,
the air-conditioning is on for an extra hour.
Parameter Setting
3601 TIMERS ENABLE DI1
3602 START TIME 1 08:00:00
3603 STOP TIME 1 15:30:00
3604 START DAY 1 MONDAY
3605 STOP DAY 1 FRIDAY
3606 START TIME 2 12:00:00
3607 STOP TIME 2 15:00:00
3608 START DAY 2 SUNDAY
3609 STOP DAY 2 SUNDAY
3622 BOOSTER SEL DI5 (cannot be the same as parameter 3601 value)
3623 BOOSTER TIME 01:00:00
3626 TIMED FUNC 1 SRC T1+T2+B
Timed function 1
3626 TIMED FUNC 1 SRC
Timed function 2
3627 TIMED FUNC 2 SRC
1001 EXT1 COMMANDS
1002 EXT2 COMMANDS
1102 EXT1/EXT2 SEL
1201 CONST SPEED SEL
1209 TIMED MODE SEL
1401 RELAY OUTPUT 1
1402 RELAY OUTPUT 2, 1403 RELAY OUTPUT 3,
1410 RELAY OUTPUT 4 (with option MREL-01 only)
1805 DO SIGNAL
4027 PID 1 PARAM SET
4228 ACTIVATE
8402 SEQ PROG START
8406 SEQ LOGIC VAL 1
8425/35/45/55/65/75/85/95 ST1 TRIG TO ST 2 …
ST8 TRIG TO ST 2
8426/36/46/56/66/76/86/96 ST1 TRIG TO ST N …
ST8 TRIG TO ST N
