270 Actual signals and parameters
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
3602 START TIME 1 Defines the daily start time 1. The time can be changed in
2-second steps.
00:00:00
00:00:00…
23:59:58
hours:minutes:seconds.
Example: If parameter value is set to 07:00:00, timed
function 1 is activated at 7:00 (7 a.m).
3603 STOP TIME 1 Defines the daily stop time 1. The time can be changed in
2-second steps.
00:00:00
00:00:00…
23:59:58
hours:minutes:seconds.
Example: If parameter value is set to 18:00:00, timed
function 1 is deactivated at 18:00 (6 p.m).
3604 START DAY 1 Defines the start day 1. MONDAY
MONDAY
Example: If parameter value is set to MONDAY, timed
function 1 is active from Monday midnight (00:00:00).
1
TUESDAY 2
WEDNESDAY 3
THURSDAY 4
FRIDAY 5
SATURDAY 6
SUNDAY 7
3605 STOP DAY 1 Defines the stop day 1. MONDAY
See parameter 3604 START DAY 1.
Example: If parameter is set to FRIDAY, timed function 1 is
deactivated on Friday midnight (23:59:58).
3606 START TIME 2 See parameter 3602 START TIME 1.
See parameter 3602 START TIME 1.
3607 STOP TIME 2 See parameter 3603 STOP TIME 1.
See parameter 3603 STOP TIME 1.
3608 START DAY 2 See parameter 3604 START DAY 1.
See parameter 3604 START DAY 1.
3609 STOP DAY 2 See parameter 3605 STOP DAY 1.
See parameter 3605 STOP DAY 1.
3610 START TIME 3 See parameter 3602 START TIME 1.
See parameter 3602 START TIME 1.
3611 STOP TIME 3 See parameter 3603
STOP TIME 1.
See parameter 3603 STOP TIME 1.
3612 START DAY 3 See parameter 3604 START DAY 1.
See parameter 3604 START DAY 1.
All parameters
No. Name/Value Description Def/FbEq
