Actual signals and parameters 199
12 CONSTANT
SPEEDS
Constant speed selection and values. See section Constant
speeds on page 142.
1201 CONST
SPEED SEL
Activates the constant speeds or selects the activation
signal.
DI3,4
NOT SEL No constant speed in use 0
DI1 Speed defined by parameter 1202 CONST SPEED 1 is
activated through digital input DI1. 1 = active, 0 = inactive.
1
DI2 Speed defined by parameter 1202 CONST SPEED 1 is
activated through digital input DI2. 1 = active, 0 = inactive.
2
DI3 Speed defined by parameter 1202 CONST SPEED 1 is
activated through digital input DI3. 1 = active, 0 = inactive.
3
DI4 Speed defined by parameter 1202 CONST SPEED 1 is
activated through digital input DI4. 1 = active, 0 = inactive.
4
DI5 Speed defined by parameter 1202 CONST SPEED 1 is
activated through digital input DI5. 1 = active, 0 = inactive.
5
DI1,2 Constant speed selection through digital inputs DI1 and
DI2.1 = DI active, 0 = DI inactive.
7
DI2,3 See selection DI1,2.8
DI3,4 See selection DI1,2.9
DI4,5 See selection DI1,2.10
DI1,2,3 Constant speed selection through digital inputs DI1, DI2 and
DI3. 1 = DI active, 0 = DI inactive.
12
DI3,4,5 See selection DI1,2,3.13
All parameters
No. Name/Value Description Def/FbEq
DI1 DI2 Operation
0 0 No constant speed
1 0 Speed defined by par. 1202 CONST SPEED 1
0 1 Speed defined by par. 1203 CONST SPEED 2
1 1 Speed defined by par. 1204 CONST SPEED 3
DI DI2 DI3 Operation
0 0 0 No constant speed
1 0 0 Speed defined by par. 1202 CONST SPEED 1
0 1 0 Speed defined by par. 1203 CONST SPEED 2
1 1 0 Speed defined by par. 1204 CONST SPEED 3
0 0 1 Speed defined by par. 1205 CONST SPEED 4
1 0 1 Speed defined by par. 1206 CONST SPEED 5
0 1 1 Speed defined by par. 1207 CONST SPEED 6
1 1 1 Speed defined by par. 1208 CONST SPEED 7
