Program features 135
Programmable relay output
The drive has one programmable relay output. It is possible to add three additional
relay outputs with the optional MREL-01 output relay module. For more information,
see MREL-01 output relay module user's manual (3AUA0000035974 [English]).
With a parameter setting it is possible to choose what information to indicate through
the relay output: Ready, running, fault, alarm, etc. The update time for the relay
output is 2 ms.
A value can be written to a relay output through a serial communication link.
 Settings
 Diagnostics
Frequency input
Digital input DI5 can be programmed as a frequency input. Frequency input
(0…16000 Hz) can be used as the external reference signal source. The update time
for the frequency input is 50 ms. Update time is shorter when information is
transferred to the application program (50 ms -> 2 ms).
 Settings
 Diagnostics
Parameter Additional information
Group 14 RELAY OUTPUTS RO value selections and operation times
8423 RO control with Sequence programming
Actual signal Additional information
0134 RO Control word through fieldbus control
0162 RO 1 status
0173 RO 2…4 status. With option MREL-01 only.
Parameter Additional information
Group 18 FREQ IN & TRAN OUT Frequency input minimum and maximum values and
filtering
1103 /1106 External reference REF1/2 through frequency input
4010, 4110, 4210 Frequency input as PID reference source
Actual signal Additional information
0161 Frequency input value
