Actual signals and parameters 301
8423 ST1 OUT
CONTROL
Selects the relay, transistor and analog output control for
Sequence programming state 1.
The relay/transistor output control must be activated by
setting parameter 1401 RELAY OUTPUT 1 / 1805 DO
SIGNAL to SEQ PROG. Analog output control must be
activated by parameter group 15 ANALOG OUTPUTS.
Analog output control values can be monitored with signal
0170 SEQ PROG AO VAL.
AO=0
RO2=RO3
=RO4=1
Relay outputs are energized (closed). Effective only with the
MREL-01 option.
-1.5
RO2=1, RO3=1 Relay outputs are energized (closed). Effective only with the
MREL-01 option.
-1.4
RO4 = 1 Relay output is energized (closed). Effective only with the
MREL-01 option.
-1.3
RO3 = 1 Relay output is energized (closed). Effective only with the
MREL-01 option.
-1.2
RO2 = 1 Relay output is energized (closed). Effective only with the
MREL-01 option.
-1.1
RST CNT
NEXT
Reserved for Enhanced Sequence Program (ESP). -1.0
RST CNT ENT Reserved for ESP. -0.8
RST CNT
STNX
Reserved for ESP. -0.9
R=0,D=1,AO=0 Relay output is de-energized (opened), transistor output is
energized and analog output is cleared.
-0.7
R=1,D=0,AO=0 Relay output is energized (closed), transistor output is de-
energized and analog output is cleared.
-0.6
R=0,D=0,AO=0 Relay and transistor outputs are de-energized (opened) and
analog output value is set to zero.
-0.5
RO=0,DO=0 Relay and transistor outputs are de-energized (opened) and
analog output control is frozen to the previously set value.
-0.4
RO=1,DO=1 Relay and transistor outputs are energized (closed) and
analog output control is frozen to the previously set value.
-0.3
DO=1 Transistor output is energized (closed) and relay output is
de-energized. Analog output control is frozen to the
previously set value.
-0.2
RO=1 Transistor output is de-energized (opened) and relay output
is energized. Analog output control is frozen to the
previously set value.
-0.1
All parameters
No. Name/Value Description Def/FbEq
