300 Actual signals and parameters
DI4U,5D Digital input DI4: Reference increase. Digital input DI5:
Reference decrease.
-0.8
DI3U,4D Digital input DI3: Reference increase. Digital input DI4:
Reference decrease.
-0.7
DI3U,4D(R) Digital input DI3: Reference increase. Digital input DI4:
Reference decrease.
-0.6
AI2 JOY Analog input AI2 as joystick. The minimum input signal runs
the motor at the maximum reference in the reverse
direction, the maximum input at the maximum reference in
the forward direction. Minimum and maximum references
are defined by parameters 1104 REF1 MIN and 1105 REF1
MAX. See parameter 1103 REF1 SELECT selection
AI1/JOYST for more information.
-0.5
AI1 JOY See selection AI2 JOY.-0.4
AI2 Analog input AI2 -0.3
AI1 Analog input AI1 -0.2
KEYPAD Control panel -0.1
0.0 …100.0% Constant speed 1 = 0.1%
8421 ST1
COMMANDS
Selects the start, stop and direction for state 1. Parameter
1002 EXT2 COMMANDS must be set to SEQ PROG.
Note: If change of direction of rotation is required,
parameter 1003 DIRECTION must be set to REQUEST.
DRIVE
STOP
DRIVE STOP Drive coast or ramps to stop depending on parameter 2102
STOP FUNCTION setting.
0
START FRW Direction or rotation is fixed to forward. If the drive is not
already running, it is started according to parameter 2101
START FUNCTION settings.
1
START REV Direction or rotation is fixed to reverse. If the drive is not
already running, it is started according to parameter 2101
START FUNCTION settings.
2
8422 ST1 RAMP Selects the acceleration/deceleration ramp time for
Sequence programming state 1, ie, defines the rate of the
reference change.
0.0 s
-0.2/-0.1/
0.0…1800.0 s
Time
When value is set to -0.2, ramp pair 2 is used. Ramp pair 2
is defined by parameters 2205…2207.
When value is set to -0.1, ramp pair 1 is used. Ramp pair 1
is defined by parameters 2202…2204.
With ramp pair 1/2, parameter 2201 ACC/DEC 1/2 SEL
must be set to SEQ PROG. See also parameters
2202…2207.
1 = 0.1 s
