Actual signals and parameters 299
NOT SEL No reset signal 0
DI1 Reset through digital input DI1. 1 = active, 0 = inactive. 1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
STATE 1 Reset during state transition to state 1. Counter is reset,
when the state has been reached.
6
STATE 2 Reset during state transition to state 2. Counter is reset,
when the state has been reached.
7
STATE 3 Reset during state transition to state 3. Counter is reset,
when the state has been reached.
8
STATE 4 Reset during state transition to state 4. Counter is reset,
when the state has been reached.
9
STATE 5 Reset during state transition to state 5. Counter is reset,
when the state has been reached.
10
STATE 6 Reset during state transition to state 6. Counter is reset,
when the state has been reached.
11
STATE 7 Reset during state transition to state 7. Counter is reset,
when the state has been reached.
12
STATE 8 Reset during state transition to state 8. Counter is reset,
when the state has been reached.
13
SEQ PROG
RST
Reset signal source defined by parameter 8404 SEQ PROG
RESET
14
8420 ST1 REF SEL Selects the source for the Sequence programming state 1
reference. Parameter is used when parameter 1103 REF1
SELECT or 1106 REF2 SELECT is set to SEQ PROG /
AI1+SEQ PROG / AI2+SEQ PROG.
Note: Constant speeds in group 12 CONSTANT SPEEDS
overwrite the selected Sequence programming reference.
0.0%
COMM 0136 COMM VALUE 2. For scaling, see Fieldbus reference
scaling on page 322.
-1.3
AI1/AI2 Reference is calculated with the following equation:
REF = AI1(%) · (50% / AI2 (%))
-1.2
AI1-AI2 Reference is calculated with the following equation:
REF = AI1(%) + 50% - AI2(%)
-1.1
AI1*AI2 Reference is calculated with the following equation:
REF = AI1(%) · (AI2(%) / 50%)
-1.0
AI1+AI2 Reference is calculated with the following equation:
REF = AI1(%) + AI2(%) - 50%
-0.9
All parameters
No. Name/Value Description Def/FbEq
