Actual signals and parameters 295
8403 SEQ PROG
PAUSE
Selects the source for the Sequence programming pause
signal. When Sequence programming pause is activated, all
timers and outputs (RO/TO/AO) are frozen. Sequence
programming state transition is possible only by parameter
8405 SEQ ST FORCE.
NOT SEL
DI1(INV) Pause signal through inverted digital input DI1. 0 = active, 1
= inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
NOT SEL No pause signal 0
DI1 Pause signal through digital input DI1. 1 = active, 0 =
inactive.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
PAUSED Sequence programming pause enabled 6
8404 SEQ PROG
RESET
Selects the source for the Sequence programming reset
signal. Sequence programming state (0168 SEQ PROG
STATE) is set to the first state and all timers and outputs
(RO/TO/AO) are set to zero.
Reset is possible only when Sequence programming is
stopped.
NOT SEL
DI1(INV) Reset through inverted digital input DI1. 0 = active, 1 =
inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
NOT SEL No reset signal 0
DI1 Reset through digital input DI1. 1 = active, 0 = inactive. 1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
RESET Reset. After reset parameter value is automatically set to
NOT SEL.
6
All parameters
No. Name/Value Description Def/FbEq
