170 Program features
Note: By default all Sequence programming parameters can be changed even when
the Sequence programming is active. It is recommended that after the Sequence
programming parameters are set, parameters are locked with parameter 1602
PARAMETER LOCK.
 Settings
 Diagnostics
Parameter Additional information
1001/1002 Start, stop and direction commands for EXT1/EXT2
1102 EXT1/EXT2 selection
1106 REF2 source
1201 Constant speed deactivation. Constant speed always
overrides the Sequence programming reference.
1401 Sequence programming output through RO 1
1402/1403/1410 Sequence programming output through relay output
RO 2…4. With option MREL-01 only.
1501 Sequence programming output through AO
1601 Run enable activation/deactivation
1805 Sequence programming output through DO
Group 19 TIMER & COUNTER State change according to counter limit
Group 32 SUPERVISION Timed state change
2201…2207 Acceleration/deceleration and ramp time settings
Group 32 SUPERVISION Supervision settings
4010/4110/4210 Sequence programming output as PID reference signal
Group 84 SEQUENCE PROG Sequence programming settings
Actual signal Additional information
0167 Sequence programming status
0168 Sequence programming active state
0169 Current state time counter
0170 Analog output PID reference control values
0171 Executed sequence counter
