Installation checklist 59
Installation checklist
What this chapter contains
This chapter contains a list for checking the mechanical and electrical installation of
the drive.
Checking the installation
Check the mechanical and electrical installation of the drive before start-up. Go
through the checklist below together with another person. Read chapter Safety on
page 17 of this manual before you work on the drive.
Check
MECHANICAL INSTALLATION
The ambient operating conditions are within allowed limits. (See Mechanical installation:
Checking the installation site on page 33 as well as Technical data: Losses, cooling data
and noise on page 382 and Ambient conditions on page 389.)
The drive is fixed properly on an even vertical non-flammable wall. (See Mechanical
installation on page 33.)
The cooling air will flow freely. (See Mechanical installation: Free space around the drive
on page 34.)
The motor and the driven equipment are ready for start. (See Planning the electrical
installation: Checking the compatibility of the motor and drive on page 40 as well as
Technical data: Motor connection data on page 385.)
ELECTRICAL INSTALLATION (See Planning the electrical installation on page 39 and
Electrical installation on page 49.)
For ungrounded and corner-grounded systems: The internal EMC filter is disconnected
(EMC screw removed).
The capacitors are reformed if the drive has been stored over a year.
