Actual signals and parameters 307
STATE 6 State 6 6
STATE 7 State 7 7
STATE 8 State 8 8
8430 ST2 REF SEL
See parameters 8420…8427.…
8497 ST8 STATE N
98 OPTIONS External serial communication activation
9802 COMM PROT
SEL
Activates the external serial communication and selects the
interface.
NOT SEL
NOT SEL No communication 0
STD MODBUS Embedded fieldbus. Interface: EIA-485 provided by optional
FMBA-01 Modbus adapter connected to drive terminal X3.
See chapter Fieldbus control with embedded fieldbus on
page 313.
1
EXT FBA The drive communicates through a fieldbus adapter module
connected to drive terminal X3. See also parameter group
51 EXT COMM MODULE.
See chapter Fieldbus control with fieldbus adapter on page
339.
4
MODBUS
RS232
Embedded fieldbus. Interface: RS-232 (ie, control panel
connector). See chapter Fieldbus control with fieldbus
adapter on page 339.
10
99 START-UP DATA Language selection. Definition of motor set-up data.
9901 LANGUAGE Selects the display language used on the assistant control
panel.
Note: With the ACS-CP-D assistant
control panel, the
following languages are available: English (0), Chinese (1),
Korean (2) and Japanese (3).
ENGLISH
ENGLISH British English 0
ENGLISH (AM) American English 1
DEUTSCH German 2
ITALIANO Italian 3
ESPAÑOL Spanish 4
PORTUGUES Portuguese 5
NEDERLANDS Dutch 6
FRANÇAIS French 7
DANSK Danish 8
SUOMI Finnish 9
SVENSKA Swedish 10
RUSSKI Russian 11
All parameters
No. Name/Value Description Def/FbEq
