Actual signals and parameters 235
2205 ACCELER
TIME 2
Defines the acceleration time 2, ie, the time required for the
speed to change from zero to the speed defined by
parameter 2008 MAXIMUM FREQ (in scalar control) / 2002
MAXIMUM SPEED (in vector control). The control mode is
selected by parameter 9904 MOTOR CTRL MODE.
See parameter 2202 ACCELER TIME 1.
Acceleration time 2 is used also as jogging acceleration
time. See parameter 1010 JOGGING SEL.
60.0 s
0.0…1800.0 s Time 1 = 0.1 s
2206 DECELER
TIME 2
Defines the deceleration time 2, ie, the time required for the
speed to change from the value defined by parameter 2008
MAXIMUM FREQ (in scalar control) / 2002 MAXIMUM
SPEED (in vector control) to zero. The control mode is
selected by parameter 9904 MOTOR CTRL MODE.
See parameter 2203 DECELER TIME 1.
Deceleration time 2 is used also as jogging deceleration
time. See parameter 1010 JOGGING SEL.
60.0 s
0.0…1800.0 s Time 1 = 0.1 s
2207 RAMP SHAPE
2
Selects the shape of the acceleration/deceleration ramp 2.
The function is deactivated during emergency stop.
During jogging, parameter value is set to zero (ie, linear
ramp). See 1010 JOGGING SEL.
0.0 =
LINEAR
0.0 = LINEAR
0.1…1000.0 s
See parameter 2204 RAMP SHAPE 1.1 = 0.1s
2208 EMERG DEC
TIME
Defines the time within which the drive is stopped if an
emergency stop is activated. See parameter 2109 EMERG
STOP SEL.
1.0 s
0.0…1800.0 s Time 1 = 0.1 s
2209 RAMP INPUT 0 Defines the control for forcing the speed to 0 with the
currently used deceleration ramp (see parameters 2203
DECELER TIME 1 and 2206 DECELER TIME 2
).
NOT SEL
NOT SEL Not selected 0
DI1 Digital input DI1. Defines digital input
DI1 as the control for
forcing the speed to zero.
• Activating the digital input forces the speed to zero, after
which the speed will stay at zero.
• De-activating the digital input: speed control resumes
normal operation.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
All parameters
No. Name/Value Description Def/FbEq
