Actual signals and parameters 231
2109 EMERG STOP
SEL
Selects the source for the external emergency stop
command.
The drive cannot be restarted before the emergency stop
command is reset.
Note: The installation must include emergency stop devices
and any other safety equipment that may be needed.
Pressing the stop key on the drive’s control panel does
NOT:
• generate an emergency stop of the motor
• separate the drive from dangerous potential.
NOT SEL
NOT SEL Emergency stop function is not selected 0
DI1 Digital input DI1. 1 = stop along the emergency stop ramp.
See parameter 2208 EMERG DEC TIME. 0 = emergency
stop command reset.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
DI1(INV) Inverted digital input DI. 0 = stop along the emergency stop
ramp. See parameter 2208 EMERG DEC TIME. 1 =
emergency stop command reset
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
2110 TORQ BOOST
CURR
Defines the maximum supplied current during torque boost.
See parameter 2101 START FUNCTION.
100%
15…300% Value as a percentage 1 = 1%
2111 STOP SIGNAL
DLY
Defines the stop signal delay time when parameter 2102
STOP FUNCTION is set to SPEED COMP.
0ms
0…10000 ms Delay time 1 = 1 ms
All parameters
No. Name/Value Description Def/FbEq
