298 Actual signals and parameters
8414 SEQ VAL 2
LOW
Defines the low limit for the state change when parameter
8425 ST1 TRIG TO ST 2 is set to, eg, AI 2 LOW 1.
0.0%
0.0…100.0% Value as a percentage 1 = 0.1%
8415 CYCLE CNT
LOC
Activates the cycle counter for Sequence programming.
Example: When parameter is set to ST6 TO NEXT, the
cycle count (0171 SEQ CYCLE CNTR) increases every
time the state changes from state 6 to state 7.
NOT SEL
NOT SEL Disabled 0
ST1 TO NEXT From state 1 to state 2 1
ST2 TO NEXT From state 2 to state 3 2
ST3 TO NEXT From state 3 to state 4 3
ST4 TO NEXT From state 4 to state 5 4
ST5 TO NEXT From state 5 to state 6 5
ST6 TO NEXT From state 6 to state 7 6
ST7 TO NEXT From state 7 to state 8 7
ST8 TO NEXT From state 8 to state 1 8
ST1 TO N From state 1 to state n. State n is defined by parameter
8427 ST1 STATE N.
9
ST2 TO N From state 2 to state n. State n is defined by parameter
8427 ST1 STATE N.
10
ST3 TO N From state 3 to state n. State n is defined by parameter
8427 ST1 STATE N.
11
ST4 TO N From state 4 to state n. State n is defined by parameter
8427 ST1 STATE N.
12
ST5 TO N From state 5 to state n. State n is defined by parameter
8427 ST1 STATE N.
13
ST6 TO N From state 6 to state n. State n is defined by parameter
8427 ST1 STATE N.
14
ST7 TO N From state 7 to state n. State n is defined by parameter
8427 ST1 STATE N.
15
ST8 TO N From state 8 to state n. State n is defined by parameter
8427 ST1 STATE N.
16
8416 CYCLE CNT
RST
Selects the source for the cycle counter reset signal (0171
SEQ CYCLE CNTR).
NOT SEL
DI1(INV) Reset through inverted digital input DI1. 0 = active, 1 =
inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
All parameters
No. Name/Value Description Def/FbEq
