SUPRV3
UNDER
See selection SUPRV3 OVER.11
TIMED FUNC 1 Logic value 1 is activated by timed function 1. See
parameter group 36 TIMED FUNCTIONS. 1 = timed
function active.
12
TIMED FUNC 2 See selection TIMED FUNC 1.13
TIMED FUNC 3 See selection TIMED FUNC 1.14
TIMED FUNC 4 See selection TIMED FUNC 1.15
8407 SEQ LOGIC
OPER 1
Selects the operation between logic value 1 and 2. Logic
operation values are used in state transitions. See
parameter 8425 ST1 TRIG TO ST 2 / 8426 ST1 TRIG TO
ST N selection LOGIC VAL.
NOT SEL
NOT SEL Logic value 1 (no logic comparison) 0
AND Logic function: AND 1
OR Logic function: OR 2
XOR Logic function: XOR 3
8408 SEQ LOGIC
VAL 2
See parameter 8406 SEQ LOGIC VAL 1. NOT SEL
See parameter 8406.
8409 SEQ LOGIC
OPER 2
Selects the operation between logic value 3 and the result
of the first logic operation defined by parameter 8407 SEQ
LOGIC OPER 1.
NOT SEL
NOT SEL Logic value 2 (no logic comparison) 0
AND Logic function: AND 1
OR Logic function: OR 2
XOR Logic function: XOR 3
8410 SEQ LOGIC
VAL 3
See parameter 8406 SEQ LOGIC VAL 1. NOT SEL
See parameter 8406.
8411 SEQ VAL 1
HIGH
Defines the high limit for the state change when parameter
8425 ST1 TRIG TO ST 2 is set to, eg, AI 1 HIGH 1.
0.0%
0.0…100.0% Value as a percentage 1 = 0.1%
8412 SEQ VAL 1
LOW
Defines the low limit for the state change when parameter
8425 ST1 TRIG TO ST 2 is set to, eg, AI 1 LOW 1.
0.0%
0.0…100.0% Value as a percentage 1 = 0.1%
8413 SEQ VAL 2
HIGH
Defines the high limit for the state change when parameter
8425
ST1 TRIG TO ST 2 is set to, eg, AI 2 HIGH 1.
0.0%
0.0…100.0% Value as a percentage 1 = 0.1%
